Weld On End

A precision-forged weld-on end designed for tractor top link and lift arm assemblies. Built from high-strength steel for superior durability, accurate fitment, and long service life in tough agricultural applications.

CODE	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)
TGF01	16.2	20	30	46	60
TGF02	19.2	44	50	52	50
TGF03	20.2	44	50	52	50
TGF04	19.2	35	50	65	43
TGF05	22.1	35	50	65	43
TGF06	22.1	35	70	76	50
TGF07	25.4	35	70	76	50
TGF08	28.2	35	70	76	50
TGF09	22.1	35	70	83	55
TGF10	25.4	35	70	83	55
TGF11	28.2	35	70	83	55
TGF12	28.2	45	70	83	55
TGF13	25.4	35	70	80	80
TGF14	28.2	35	70	80	80
TGF15	28.2	45	70	80	80
TGF16	22.1	45	70	80	65
TGF17	25.4	45	70	80	65
TGF18	28.4	45	70	80	65
TGF19	30.2	45	70	80	65
TGF20	28.2	45	70	96	65
TGF21	34.4	45	70	96	65
TGF22	35.2	45	70	96	65
TGF23	37.4	45	70	96	65
TGF24	19.2	35	56	67	50
TGF25	22.1	35	56	67	50
TGF26	25.4	35	56	67	50
TGF27	22.1	35	58	67	75
TGF28	25.1	45	70	80	80
TGF29	28.2	45	90	106	90
TGF30	30.2	45	90	106	90
TGF31	34.4	45	90	106	90
TGF32	35.2	45	90	106	90
TGF33	37.4	45	90	106	90
TGF34	38.4	45	90	106	90
TGF35	28.4	45	70	80	110

Quality You Can Trust

ISO 9001

Quality Management System certification ensuring consistent product quality.

ISO 14001

Environmental Management System for sustainable manufacturing practices.

OEM-Grade Fitment

Guaranteed compatibility and performance meeting original equipment standards.

Product Description

The TRACFORGE Weld-On End is engineered for high-performance agricultural and industrial machinery. Manufactured from heavy-duty forged steel, it provides exceptional strength and reliability for top link assemblies, lift arms, stabilizers, and custom linkage builds.

Its precision-machined eye ensures smooth articulation, while the robust weldable base guarantees secure attachment to pipes, arms, or fabricated structures. Available in multiple sizes and configurations (as per chart), this weld-on end is ideal for tractors, implements, and heavy-duty mechanical applications requiring maximum durability and perfect alignment.
